SPARE PARTS
PART
NO.
DESCRIPTION
EV700 EV900 EV1200
1
Front Filter Screen - for Sponge
31EV130
2 Sponge
3
Flow Control Knob - [EV700 - EV1200 Only]
31EV127
4
Front Filter Screen - With Hole for Flow Control -
[EV700 - EV1200 Only]
Not Shown
Blanking Cap for Hole in Front Filter Screen
(optional)
5
1" Coupling Fitting x 2 - for inlet & outlet
31EV126
6
Impeller Cover Housing
31EV125
31EV155
31EV175
7
Impeller Assembly
8
Impeller O'ring
31EV129
9
Base Plate with Rubber Feet
10
Pump Motor Body
11
1” x 1-1/2” Reducer Bushing Fitting
12
Washer - for Locking Nut (Red)
13
3/4”, 1”, 1-1/4” & 1-1/2” Barbed Hosetail
with Locking Nut
5, 11, 12, 13
Complete Kit EV700-EV1200
- Coupling Fitting x2, Reducer Bushing Fittings,
Washer (Red) & Barbed Hosetail with Locking Nut
31EV128
