PORT SHIELD - Installation Instructions; Determining The Deadbolt Direction

Determining The Deadbolt Direction
“Left Open” Setup “Right Open” Setup Instructions
1
Always keep the
spindle in the
horizontal
position
2
Always keep the
deadbolt pulled in
3
Determine the
proper direction
(handing) for your
deadbolt to open.
4
Adjust the Switch
on the back panel
to “L” or “R”
accordingly
5 Deadbolt knob
ATTENTION: Follow instructions carefully to avoid installation issues.
Installation Instructions
6
