CAUTION! Incorrect installation may result in the device falling and may
damage it or cause damage to other objects!
CAUTION! Always use only original spigots and cotters to install or hang the
fixture. Never use other brands’ spigots.
REMEMBER! Never use more than two units on base or on the hanging clamp
without additional safety support.
Operation modes
The luminaire can work in three operation modes: DMX, MASTER and SLAVE. DMX mode is designed to
work with DMX consoles. MASTER mode is designed to operate the fixture manually, without an external
controlling signal. In the MASTER mode, the fixture sends a controlling signal on the DMX output socket.
The signal can control other units in SLAVE mode. Please consider that unit in MASTER mode connected to
a regular DMX chain can corrupt DMX signal quality. The SLAVE mode allows you to control the fixture with
the control signal sent from a unit in MASTER mode. However, the DMX signal has got the highest priority
and the fixture always reacts to the connected DMX signal regardless of the operating mode.
Receives control signal from
Master unit
Gets back to the last Macro or
Manual setting
Receives control signal from
Master unit
Gets back to the last Macro or
Manual setting
Receives control signal from
Master unit
There are three ways to operate the fixture in the DMX OPERATING MODE. You can use DMX input signal,
onboard manual control or WDMX input signal to control the fixture(if the WDMX card is installed). You can
link the fixture to a DMX controller using a 5 pin DMX wire, or Wireless Solution Sweden hardware (if the
WDMX card is installed). You can control each channel individually whether with a DMX controller or a
manual control build in the fixture. The fixture has 6 DMX personalities and it supports RDM. In DMX mode
fixture will not remember the manual settings after a reset is performed.
