GAM Quick Installation Guide
Positron Access Solutions 12 Document 180-0211-001 R01
The SFP+ port of the GAM has a dedicated status LED located underneath the
SFP+ cage.
Figure 8: SFP+ LED
LED
Condition
Function
Located under SFP+
connector
Off
Green
Blinking green
Disabled or Link is Down
Link is Up
Link Activity
Table 3: SFP+ LED indicator
1.2.6 GAM Reset Button
Press the RST button to reset the GAM. When depressed for two (2) to ten (10)
seconds, it will perform a cold reboot of the GAM. When depressed for more than
ten (10) seconds, it will return the GAM device to its original factory default settings
and will perform a cold reboot of the GAM.
SFP+ LED
