GAM Quick Installation Guide

Positron Access Solutions 15 Document 180-0211-001 R01

2.1 Step by Step Installation Procedure

Here is a step-by-step procedure to install the GAM-8-MX or GAM-4-MX outdoor

unit.

Note: The Copper cable binder shown does not ship with the GAM-8-MX or GAM-4-MX

Let us begin with the insertion and connection of the copper binder cable.

Step 1: The GAM-8-MX / GAM-4-MX ships with

a protective insert to prevent dust from entering

the enclosure via the left grommet used for the

copper cable binder.

Step 2: Remove the protective (red) insert by

removing the sealing nut of the cable gland
