Figure 3
1. Printhead Module 2. Printhead Bracket 3. Printhead
4. Media Sensor 5. Platen Roller 6. TPH Release Lever
7. Media Guide 8. Ribbon Loading Knob 9. Ribbon Supply Spindle
10. Media Compartment 11.Guide Wheel
1
2
3
4
5
6
7
8
9
10
11
