3
Chapter 1 Introduction
Specifications
Specifications for Printer
Model C168/200s C168/300s
Printing method Direct thermal & Thermal transfer
Printing resolution 203 dpi (8 dots/mm) 300 dpi (11.8 dots/mm)
Max printing speed 4 ips /s (101.6 mm) 3 ips (76.2 mm/s)
Max printing width 4.09″(104 mm) 4.25″(108 mm)
Max printing length 157″ (4000 mm) 79″ (2000 mm)
Memory 2 MB FLASH ROM, 8 MB SDRAM
Media
Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain
paper or thermal paper
Width：110 mm max., 25 mm min.
Supply roll: OD 4″(102 mm) max., ID 1″(25.4 mm) min.
Thickness: 0.003″～0.007″ (0.08～0.18 mm), including liner
Ribbon
Wax, Wax/Resin, Resin
Ribbon roll: OD 3″(76.2 mm) max., ID 1″(25.4 mm) core
Max width: 110 mm; Max length: 360 M
Fonts Five built-in ASCII fonts; Optional multiple language fonts
Bar Code Types
1D Barcode : Code 39, Code 93, Code 128/subset A,B,C,
Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on,
EAN-13/8/128, UCC-128, etc.
2D Barcode : MaxiCode, PDF417, Data matrix, etc.
Media sensor Reflective (Adjustable)
Interfaces RS-232 serial, USB
Power rating* 24 VDC, 2.0 A
Weight 2.8 kgs
