33
The variables that can be set for the Pulse channels are:
Option
What it does
Input type
‘Reset’ – when the unit has transmitted the readings, it will reset the pulse count
value
‘Continue counting’ – when the unit has transmitted the readings, it will continue
on from the current pulse value
Prescaler
The number of counted pulses is divided by this value. So if the prescaler = 2,
100 pulses is reported as 50 units.
Units
The engineering units that you are measuring each count in.
