Powell FlexTrol Class E2 User Manual

Powered by Safety
®
2
01.4IB.46300
General Information
FlexTrol™ Class E2 Medium Voltage Controllers with
Eaton Contactor
a. scope
The information in this instruction bulletin
describes the following FlexTrol™ Class E2
Medium Voltage Controllers (E2):
• 5.0kV, and 7.2kV Voltage Class for 400A
• 5.0kV, and 7.2kV Voltage Class for 800A
Note: You may see the Class E2 equipment
referred to as MVMCC.
B. purpose
The information in this instruction bulletin
is intended to provide information required
to properly operate and maintain FlexTrol
medium voltage controllers described in
Ch 1 General Information, A. Scope.
This instruction bulletin provides:
1. Safety guidelines
2. General descriptions of the operation and
maintenance of FlexTrol medium voltage
controllers
3. Instructions for installation and placing
FlexTrol medium voltage controllers into
service
4. Instructions for part replacement
5. Information for ordering renewal parts
6. Procedure for critical adjustments
7. Illustrations, photographs, and description
of the controllers
The illustrations contained in this document
may not represent the exact construction
details of each particular type of FlexTrol
Class E2 Medium Voltage Controllers. The
illustrations in this document are provided
as general information to aid in showing
component locations only.
All illustrations and photos are shown using
deenergized equipment.
Follow the appropriate safety precautions
while handling any of the equipment. Failure
to do so may result in death or serious injury.
!
WARNING
To the extent required, the products described
herein meet the applicable ANSI, IEEE, and
NEMA Standards; however, no such assurance
is given with respect to local codes and
ordinances which may vary greatly.
c. instruction Bulletins availaBle electronically
Changes to the instruction bulletin may be
implemented at any time and without notice.
Go to powellind.com to ensure use of the current
instruction bulletin for Powell equipment.
NOTICE
For more information visit powellind.com.
To contact the Powell Service Division call
1.800.480.7273, or email
info@powellservice.com.
For specific questions or comments pertaining
to this instruction bulletin email
documents@powellind.com with the IB number
in the subject line.
D. associateD Bulletins
• 01.4IB.65220A Lift Devices for use
with PowlVac® and PowlVac-AR®, 5kV &
15kV Switchgear and PowlVac 38™ and
PowlVac38-AR™ Switchgear
