Powered by Safety
®
49
01.4IB.46300
Recommended Renewal Parts and Replacement Procedures
Table M Medium Voltage Vacuum Contactor Eaton 800A SL Renewal/Replacement Parts
Description Part Number
120V Control
Three (3) Vacuum Bottles with Shunt, Support, & Fingers 2147A87G03
Contactor Coils
120VAC (Set of 2) 2147A88G11
240VAC (Set of 2) 2147A88G12
Contactor Tune-Up Kit 2147A99G04
Contactor Miscellaneous Parts Kit 2147A88G15
Contactor Magnet Assembly with Coil
120VAC 2147A88G02
240VAC 2147A88G03
Contactor Magnet Assembly without Coil 2147A88G04
Interlocks
L-63 Interlock (Coil Circuit) 578D461G03
L-64 Auxiliary Interlocks 1NO/1NC 843D943G21
L-64 Auxiliary Interlocks 2 NO 843D943G22
L-64 Auxiliary Interlocks 2 NC 843D943G23
Barrier Assemblies
Contactor Barrier Assembly 2147A89G07
Contactor Fuse Support & Barrier Assembly 2147A89G06
Load or Line Fingers
Contactor Line Fingers with Copper Support 2147A89G01
Contactor Line or Load Fingers without Copper Support 2147A89G02
Contactor Fuse Load Fingers (Between Contactor & Fuse) (Set of 3) 2147A71G15
CPT & PT Primary Fuses
0.81-inch dia. 5kV Max, 1 Amp (Set of 3) 2147A11G61
0.81-inch dia. 5kV Max, 3 Amp (Set of 3) 2147A11G49
0.81-inch dia. 5kV Max, 5 Amp (Set of 3) 2147A11G55
1.00-inch dia. 5kV Max, 1 Amp (Set of 3) 2147A11G63
1.00-inch dia. 5kV Max, 3 Amp (Set of 3) 2147A11G46
1.00-inch dia. 5kV Max, 5 Amp (Set of 3) 2147A11G53
Isolation Switches
Isolation Switch Handle, Housing, & Clevis 2147A71G08
Isolation Switch Tray Assembly with Line Fingers 2147A81G22
Isolation Switch Microswitch Assembly 2147A01G01
