01.4IB.46300

Installation

FlexTrol™ Class E2 Medium Voltage Controllers with

Eaton Contactor

Figure 16 FlexTrol™ - 400A

a. Isolation Switch and Shutter

b. Load Terminals

c. Power Fuses

d. Ground Connection

e. Contactor

Figure 17 FlexTrol™ - 800A

a. Load Terminals

b. Isolation Switch and Shutter

c. Power Fuses

d. Contactor

e. Ground Connection
