01.4IB.46300

Recommended Renewal Parts and Replacement Procedures

FlexTrol™ Class E2 Medium Voltage Controllers with

Eaton Contactor

Table U Control Power Transformers - SNC

Part Number Description

P21847 1kVA, 2400V-120V

P21848 1kVA, 4200V-120V

P21850 1kVA, 7200V-120V

P21876 1kVA, 2400-120/240V

P21877 1kVA, 4200-120/240V

P21852 2kVA, 2400V-120V

P21853 2kVA, 4200V-120V

P21854 2kVA, 7200V-120V

Table V Control Power Transformer Primary Fuses

400A Contactor 2.4 & 5.5kV (fuse holder not required)

Part Number Description

A500T1E-1 1E, 5kV fuses for 1kVA CPT

A500T2E-1 2E, 5kV fuses for 2kVA CPT

400A Contactor 7.2kV (fuse holder not required)

Part Number Description

A720T1E-1 1E, 7.2kV fuses for 1kVA CPT

A720T2E-1 2E, 7.2kV fuses for 2kVA CPT

800A Contactor 2.4 & 5.5kV (fuse holder required)

Part Number Description

2033A73G03 C-H, MV fuse holder

A500T1E-1 1E, 5kV fuses for 1kVA CPT

A500T2E-1 2E, 5kV fuses for 2kVA CPT

800A Contactor 7.2kV (fuse holder required)

Part Number Description

2033A73G03 C-H, MV fuse holder

2103A88H01 C-H fuse clip adapter plate

8NCLPT-1E C-H, 7.2kV fuses for 1kVA CPT

8NCLPT-2E C-H, 7.2kV fuses for 2kVA CPT

Powell FlexTrol Class E2 User Manual
