Powered by Safety
®
17
01.4IB.46300
Equipment Description
k. starting autotransForMers or reactors
Reduced-voltage starters include a reactor or
autotransformer designed for starting duty in
accordance with NEMA ICS 3. The duty cycle
for the medium-duty application is three starts,
30 seconds apart, followed by a one-hour rest.
A heavier-duty cycle will cause overheating
and possible damage to the reactor or
autotransformer.
l. DiMensions
Refer to the equipment drawings for the
specific dimensions and an outline of the
equipment. The FlexTrol™ 400A application is
normally a one-high or two-high construction
with typical dimensions of 36" in width, 36" in
depth, and 107" in height. The
FlexTrol 800A application is normally a
one-high construction with typical dimensions
of 36" in width, 36" in depth, and 107" in
height. These dimensions exclude channel
bases, plenums, and lifting members for indoor
construction. For typical outline dimensions
refer to Figure 7.
