Recommended Renewal Parts and Replacement Procedures

2) Auxiliary Contacts Inspection and

Replacement

CAUTION

Deenergize the equipment before performing

any maintenance work. Failure to do so may

result in injury or death to the operating

personnel.

a. Inspect the auxiliary contacts for wear,

scorching or heat damage. Replace any

damaged contacts. The contact have

a mean time between failure (MTBF)

rating of 20 million operations if used

within the operating specifications.

b. To remove the contact, turn both the

D-head fasteners until the flat sections

are aligned with the edge of the

contact.

c. Remove the contact from the housing.

d. Disconnect the wires from the auxiliary

contact.

e. Reverse steps b through d to install the

new auxiliary contact.

f. Ensure the contact is correctly

positioned into the contact carrier.
