Power Acoustik PD-710B - 99-7000 Kit Assembly; 2-Shaft Radio Provision Installation; DIN Radio Provision Installation

1. Attach the faceplate to
radio housing.
2.
Slide the aftermarket radio into
the kit and secure with shaft nuts.
(Figure A)
3.
Locate the factory wiring harness
in the dash. Metra recommends
using the proper mating adapter
from Metra or AXXESS. Re-connect
the negative battery terminal and
test the unit for proper operation.
4.
Reassemble dash in reverse order
of disassembly.
(Figure A)
(Figure A)
1. Cut and remove the shaft supports.
2. Slide the DIN cage into the radio
housing and secure by bending the
metal locking tabs down.
3.
Slide the aftermarket radio into the
cage until secure. (Figure A)
Note: If an equalizer will be
included, slide the unit into the
back of the radio housing and
secure. If an equalizer will NOT
be included, snap the equalizer
dummy plate into the opening.
4.
Locate the factory wiring harness
in the dash. Metra recommends
using the proper mating adapter
from Metra or AXXESS. Re-connect
the negative battery terminal and
test the unit for proper operation.
5.
Reassemble dash in reverse order
of disassembly. (Figure B)
5.6
2-Shaft radio provision DIN radio provision
Kit Assembly 99-7000
(Figure B)
