Power Acoustik RAZOR RZR1-2500D User Manual

Features RZR1-2500D
• Class - D 1-Channel Amplifier ( 2 - ohm Stable)
• Applying New Concept "Low-Heat Producing Circuit".
• One - Channel Monoblock Design
• Full MOSFET DC-DC PWM Power Supply.
• Four way Amplifier Protection.
• Double Sided FR-4 PC Board.
• SMD Amplifier Technology.
• Hi-Level Input Capability.
• Remote Dash Mounted Gain Control.
• Nickel Plated RCA Input Connectors.
• Adjustable Low-Pass, Bass Boost, Subsonic Controls.
• 8 Gauge Input Power Terminal and 8 Gauge Speaker Out Block Terminal.
• Ultra Slim Digital Amplifier Profile
Specification
• 450W x 1 Ch. 4 - Ohm Mono
• 650W x 1 Ch. 2 - Ohm Mono
• 2,500W Max Power Rating
• Variable 35Hz-250Hz 12dB Low Pass Filter
• Variable 10Hz-50Hz 12dB Subsonic Filter
• Variable 0dB-12dB At 45Hz Bass Boost
• Total Harmonic Distortion : 0.5%
• Frequency Response : 20Hz-150KHz
• Signal - to - Noise Ratio : 85dB
• Damping Factor: >100
• Input Sensitivity: 250mV - 6.0V
• Amplifier Dimension 4.75" W x 1.75" H x 11" L

-o
0
1

Power Acoustik RAZOR RZR1-2500D Specifications

General

Class	D
Max Power Output	2500W
Signal-to-Noise Ratio	>95dB
Number of Channels	1
THD at RMS Output	<0.5%
Input Sensitivity	200mV - 6V
Crossover Type	Low-Pass
Subsonic Filter	10Hz - 50Hz
Bass Boost Frequency	45Hz
Bass Boost	0dB - 18dB
RMS Power at 1 Ohm	1250W x 1
