Power Acoustik RAZOR RZR1-2500D User Manual

Hi-Level Input Connections
The hi-level inputs are for use with speaker-level wiring. Most factory source units do not have
RCA outputs. Use this connection if your source unit does not have RCA outputs. The amplifier will
automatically turn off and on using hi-level inputs, no need for remote wire input.
CAUTION: Never use the hi and low-level inputs at the same time!
RZR1-2500D

0
 -  

Speaker Output
RCA Input Connection
RZR1-2500D

0



HEAD UNIT
HEAD UNIT
3

Power Acoustik RAZOR RZR1-2500D Specifications

General

Class	D
Max Power Output	2500W
Signal-to-Noise Ratio	>95dB
Number of Channels	1
THD at RMS Output	<0.5%
Input Sensitivity	200mV - 6V
Crossover Type	Low-Pass
Subsonic Filter	10Hz - 50Hz
Bass Boost Frequency	45Hz
Bass Boost	0dB - 18dB
RMS Power at 1 Ohm	1250W x 1
