Power Breezer Mach 4+ - Page 18

Make sure to unplug the unit while checking connecons or anything pertaining to the
electronic box and plug back in when tesng.
A. Open the E-Box:
1. Remove the 2 lower hex bolts with a 13 mm socket.
2. Slide the E-Box out like a dresser drawer.
3. Turn the E-Box upside-down.
4. Remove the two screws securing the lid with a 3 mm Allen wrench.
B. The wiring diagram for the E-Box (180-700-750-wiring drawing) has the DC Pump Cable
wiring instrucons on the boom of the page.
C. Disconnect the DC Pump Cable from the E-Box:
1. Each wire of the pump goes into a “Phoenix” connector.
2. These connectors have a round hole the wire enters and a square hole next to it
that is used to release the wire.
3. Remove the wire from the connector using a small flat head screwdriver with the
flat end facing up. Then move the screwdriver past the wire to the back of the
square hole and insert the screwdriver perpendicularly into the connector. This
will release the wire.
4. Remove the water pump wires from the E-Box.
D. Locate the Control Panel on the Power Breezer and li the tray that the Control Panel is
seated in; this will expose the DC Pump Cable going from the E-Box to the tank. Pull the
DC Pump Cable up from the E-Box.
E. Go to the Tank and pull the DC Pump Cable through and place the defecve cable in a
container for analysis at a later date.
F. Take the New DC Pump Cable and thread it through the same path as the old DC Pump
Cable to the E-Box.
G. Connect the DC Pump to the E-Box per the wiring diagram.
H. Test the new water pump and the Power Breezer.
I. Close the E-Box.
You have reached the last page of the Troubleshoong Guide for Power Breezer Mach 4+. If
your Cooling Unit’s problems cannot be resolved using the procedures found in this guide,
please contact Customer Service by email at customerservice@powerbreezer.com or by phone
at 844-233-5673.
