VS65 SERIES MV SOFT STARTER
2. STATUS MESSAGES
Figure 7.1 Display Status Messages
The soft starter is applying the initial torque shown in [G4.4] during the
specified time given in [G4.5].
Motor accelerating phase.
The soft starter runs at nominal speed, after completing the accelerating
ramp. (Input voltage = Output Voltage).
Motor decelerating phase.
The hammer hit decelerating algorithm is running.
Under power voltage warning.
Over power voltage warning.
Excessive temperature in the soft starter.
Motor asymmetric current.
Fault in soft starter produced.
The soft starter is waiting the time given in the parameter [G4.1]. Start
delay.
Fault status due to an external fault caused by a digital input.
The soft starter applies torque pulse configured in the parameter [G4.2]
Torque pulse during the time given in parameter [G4.3] Torque pulse time.
The soft starter has reached the maximum current consumption in
accordance with the parameter [G4.7] Limit acceleration current.
Overpressure warning during the time settled in parameter [G16.4]
Under pressure warning during the time settled in parameters [G16.5] and
[G16.6].
Cavitations warning during the time settled on screens [G16.7] and [G16.8].
Water low level warning during the time settled on screen [G16.9].
1. Indicates the soft starters run order control mode (L) Local, (R) Remote,
(C) series Communication, (G) Slow Speed, (P) Pump control.
2. Equipment status. See the status message list. RUN = RUNNING.
3. Motor mean current consumption.
4. VS65 input Medium Voltage.
