Power Electronics VS65 Series Programming And Software Manual

VS65 SERIES MV SOFT STARTER
POWER ELECTRONICS
40
CONFIGURATION REGISTER
8. CONFIGURATION REGISTER
DIGITAL SOFT STARTER: VS65
SERIAL Nº:
MODEL:
APPLICATION : SERIE
DATE:
CUSTOMER :
SCREENS
RANGE
DEFAULT
RECORD 1
RECORD 2
G1 MENU OPTIONS
1 LOCK PARAM=
Yes/No
N0
2 PASSWORD=
0000-9999
0
3 WRONG P/W=
0000-9999
XXXX
4 LANGUE=
Span., Eng., D
ENGLISH
5 INITIALISE=
Yes/No
NO
6 COMMISSION=
Yes/No
YES
G2 NAMEPLATE
1 ISTARTER=
9 - 1600
_ _ _A*
2 I MOTOR=
1 - 1600
_ _ _A *
3 V MOTOR=
1/2/3/4
2*
4 P MOTOR=
4 - 999
_ _ _KW
5 COS PHI M=
40 – 99%
85%
6 FREQ=
50/60
50Hz
G3 PROTECTIONS
1 PHASE SEQUEN=
1/2/3
2*
2 OV LOAD=
0,5-1,5 I
VS65
1 x I
3 OV/LOAD T=
1-10
5
4 OVL FAC=
100-500%
100%
6 UNLOAD=
0-0,8
0.0A
7 UNLOAD T=
0-99/Off
OFF
8 SHRPIN=
0,6-1,2/Off
OFF
9 ASYM I ENB=
Yes/No
YES
10 UNDER V=
162-450
5052V
11 U/V DELAY=
0-10/Off
5s
12 OVERVOLT=
254-575
6947V
13 O/V DELAY=
0-10/Off
5s
14 START LIMIT=
1-10
3
15 STR/ INT=
0-60/Off
15Min
G4 ACCELERATION
1 STR DELAY=
0-600
0s
2 PULS TORQ=
50-99%
50%
3 PULS TQ T=
0,1-0,9/Off
OFF
4 INIT TORQ=
0-100%
35%
5 INIT TQ T=
0-99
1s
* See section ’11 SCREEN DESCRIPTION’.
