Power Electronics VS65 Series Programming And Software Manual

POWER ELECTRONICS
VS65 SERIES MV SOFT STARTER
CONFIGURATION REGISTER
41
E
N
G
L
I
S
H
SCREENS
RANGE
DEFAULT
RECORD 1
RECORD 2
6 ACEL TIME=
0-180
6s
7 I LIMIT=
1.5 - 5 x In
xxxxA
G5 DECELERATION
1 FREWEL STP=
Yes/No
YES
2 DECL TIME=
0-180
12s
3 DEC MD SEL=
1/2
1*
4 HAMR FACT=
0-100%
75%
5 MINI TORQ=
0-80%
1%
G6 INPUTS
1 OPER MODE=
1/2/3/4/5
1*
2 LOCAL RESET=
Yes/No
Y
3 DINPUT1 SEL=
0-10
4*
4 DINPUT2 SEL=
0-10
0*
5 DINPUT3 SEL=
0-10
0*
6 DINPUT4 SEL=
0-10
0*
7 DINPUT5 SEL=
0-10
0*
8 ANI1 FORMAT=
0/1/2
1
9 AI1 RANGE=
0-100
0-10
10 AI1 UNITS=
Off/Bar/°C/m
OFF
11 ANI2 FORMAT=
0/1/2
1
12 AI2RANGE=
0-100
0-10
13 AI2 UNITS=
Off /Bar/°C/m
OFF
G7 OUTPUTS
1 REL1 SEL ON=
1-21
14*
2 REL2 SEL ON=
1-21
15*
3 REL3 SEL ON=
1-21
9*
4 ANLOG1 SEL=
0-7
0*
5 AO1 FORMAT=
0/1
0*
6 AO1 LOW=
0-500
0%
7 AO1 HIGH=
0-500
100%
G8 DUAL SETTING
1 DUALSETING=
Yes/No
NO
2 PLS TORQ2=
50-99%
50%
3 PLS TQ T2=
0,1-0,9/Off
OFF
4 INIT TRQ2=
0-100%/Off
30%
5 INIT TQ T2=
0-99
1s
6 ACC TIME2=
0-180
12s
7 I LIMIT2=
1-5 I
VS65
xxxxA
8 FREWEL STP2=
Yes/No
N
9 DEC TIME2=
0-180
12s
10 DEC MD SEL2=
1/2
1
11 HAMR FAC2=
0-99
75
12 MINI TRQ2=
1-99%
1%
13 PHASE SEQ2=
1/2/3
2s
* See section ’10 SCREEN DESCRIPTION’.
