MOVE ZR Installation & Owner’s Guide | 7
Label DESCRIPTION QTY.
Trolling Motor Assembly and Hardware
1 Trolling Motor Assembly 1
2 1/4" x 20, 2 3/4" Stainless Full-Thread Hex Head Bolt 6
3 1/4" Small Stainless Flat Washer 6
4 1/4" Rubber Washer 6
5 1/4" Large Stainless Flat Washer 6
6 1/4" Brass tall Nylon Lock Nut 6
7 Heat Shrink Ring Terminal, 8 AWG, 1/4" 2
8 Heat Shrink Ring Terminal, 8 AWG, 3/8" 2
9 Tech Flow Propeller 1
10 Nylon Locking Anode Assembly 1
11 Shear Pin - Propeller 2
12 Tie Down Strap 1
Display Assembly and Hardware
13 Display Base 1
14 Info Display Assembly 1
15 Screw, Sheet Metal, Flat Head Phillips Drive 2
16 Heat Shrink Ring Terminal, 18-22 AWG, #10 2
17 Heat Shrink Ring Terminal, 18-22 AWG, 3/8" 2
18 Heat Shrink Butt Connector, 18-22 AWG 1
19 Fuse Holder, ATC, and ATO 18 AWG, Red Leads 1
Foot Buttons and Hardware
20 #8 x 1 1/4" Pan Head Sheet Metal Screw 6
21 Active Heading Mode Foot Button 1
22 Anchor Mode Foot Button 1
INSTALLING THE MOVE ZR
WHAT’S IN YOUR BOX?
The MOVE comes ready to be installed right out of the box. No complicated assembly is required.
We also included everything you need to have a great day on the water.
PARTS LIST
