Power Probe IV User Manual

Power Probe IV
www.powerprobe.com · 800-655-3585
Tool Repair Operations
Circuit Breaker Replacement
Page 21
Follow the instructions below to replace a worn Circuit Breaker -
Unscrew the two retaining screws and remove the rear cover.
Using an appropriate pry tool or small screwdriver, carefully
pry the Circuit Breaker towards the tip to dis-engage it from
the breaker terminals. Do not apply excessive force.
Once the Circuit Breaker is loose from the terminals, carefully
lift the breaker from the housing cavity.
Position the new Circuit Breaker into the housing, take care
to line up the breaker spades with the breaker terminals, and
press down gently until the Circuit Breaker is fully engaged
into the breaker terminals.
Replace the rear cover and the two retaining screws.
