10
The generator i s equipped with an equipment ground connecting the generator frame and
the ground terminals on t he AC output receptacles. This allows the generator to be used as a portable
without grounding the frame of the generator.
The generator (stator winding) is isolated from the frame and from the AC receptacle ground pin. Electrical
devices that require a grounded receptacle pin connecti on will not function if the receptacle ground pin is
not functional.
ECO Sw itch
When the energy-saving switch is in the energy-saving position, the generator is in the energy-saving state.
When disconnecting or using low power, the engine automatically returns to a low speed s tate, thus
reducing engine fuel consumption
Full Speed
“full speed” means that the energy-saving state(ECO s witch) is in OFF position and the engine i s always at
high speed, which is suitable for the situation where the load of electrical appliances varies greatly.
When the energ
y-saving switch is in full-speed position, the engine will remain in a hi gh speed state.
● In order to reduce the change of vol tage, the energy saving switch should be in the position of "full
speed" when t he electrical equipment needs a large instantaneous power, or when the generator is
connected with the load of the high power apparatus at the same tim e.
● When using 12 V DC output, put the energy-saving switch in full-speed position.
WARNING: In t he non-overload state, th
e output can not be restored by pressing the reset key.
Each time the engine is started, the number of effective operation times of the protection cut-off
switch is 5 times, or the engine needs to be restarted.
Fuel Tank Cap
Remove the fuel tank cap by rotating it anticlockwise to add fuel.
During parallel operati on, energy-saving switches of generating sets should be in the s ame position. To
parallel operation, perform the following steps:
1. Connect one generating set to oth
er generating set(s) in parallel. Use the parallel kit to make the parallel
connection (the parallel kit needs to be purchased separately).
2. Start the engine i n proper order and make sure that the running indicator (green) is normal.
3. Connect the plug of electri c devices to the AC receptacl e of parallel kit.
4. Run the electric devices.
NOTE: We advise two parallel generators are same model, or it may cause a low voltage output, which
could damage appliances powered by th
e generators.
Parallel Operation
Make sure that the generating s et is in a good running state before connecting it to other generating sets.
The total power of electric devices should not exceed rated power of generating set.
When electric m otor starts, the overload indicator will light up and normally it will stop within4 seconds. If
it cannot st op, please call 1-872-314-0005 Mon-Fri 9-5 EST or email: support@powersmartusa.com &
support@amerisuninc.com for customer service.
