6. The finished Truss will look as follows -
7. Repeat this process for all other trusses. The number of trusses required will be as follows:
4x8 – 1 truss
6x8 – 1 truss
8x8 – 1 truss
10x8 – 2 trusses
12x8 – 2 trusses
14x8 – 3 trusses
16x8 – 3 trusses
18x8 – 4 trusses
20x8 – 4 trusses
Roof
As separate set of instructions explaining the roof installation process for your specific shed will be attached to the
pallet.
Please note – The tongue & groove roof panels do NOT interlock as the panels are butt jointed together.
Roof Instructions Example -
