Please note
- Cover lats, which are for each corner of the building and to cover any join in each panel (vert
ically from the outside) are the pieces of timber
which are 12mm x 58mm thick. - Bargeboards, which are for the edges of the roof (although please carefully read the instructions where to put them as some g
o under the felt
and some over the felt) are
the pieces of timber which are 12mm x 70mm thick.
1190mm
Heavy
Duty
Bearer
Truss Left Truss Right
Truss
1520mm
Framing
Truss
Support
Piece
Bargeboard
1801mm
x58mm
Cover Lat
Diamon
Finial
Felt
Fixing
Pack
4x8 4 0 0 0 0 4 7 2
12ft Piece @ 1m wide
4ft Piece @ 0.5m wide
2
6x8 4 1 1 1 1 4 9 2
12ft Piece @ 1m wide
6ft Piece @ 1m wide
6ft Piece @ 0.5m wide
2
8x8 4 1 1 1 1 4 9 2
16ft Piece @ 1m wide
8ft Piece @ 1m wide
8ft Piece @ 0.5m wide
2
10x8 4 2 2 2 2 4 11 2
20ft Piece @ 1m wide
10ft Piece @ 1m wide
10ft Piece @ 0.5m wide
2
12x8 4 2 2 2 2 4 11 2
(3x) 12ft Piece @ 1m wide
12ft Piece @ 0.5m wide
2
14x8 4 3 3 3 3 4 13 2
(3x) 14ft Piece @ 1m wide
14ft Piece @ 0.5m wide
2
16x8 4 3 3 3 3 4 13 2
(3x) 16ft Piece @ 1m wide
16ft Piece @ 0.5m wide
2
18x8 4 4 4 4 4 4 15 2
(3x) 18ft Piece @ 1m wide
18ft Piece @ 0.5m wide
2
20x8 4 4 4 4 4 4 15 2
(3x) 20ft Piece @ 1m wide
20ft Piece @ 0.5m wide
2
