Power2max NGeco Manual

You need an ANT+-compatible head unit that supports the power-only profile (PWR). For
example, suitable head units are:
- CYCLEOPS: Joule 2.0 and 3.0
- GARMIN: Edge 500/510/520/800/810/820/1000, Forerunner 310XT/910XT
- O-SYNCE: navi2coach, Macro X and Macro High X
You can find a current list of compatible products at the ANT+ Alliance:
http://www.thisisant.com/directory/power2max-road-rotor-3d-plus-bcd-110-or-130/
In addition, your power2max NG power meter offers the option of using a Bluetooth
low-energy compatible display instrument (BLE) that supports the Cycling Power Profile.
The data for power and cadence are calculated and transmitted. By optional payable
upgrade: torque, left-right distribution and pedal smoothness are calculated and transmit-
ted additionally.
INSTALLATION
Step 1
First install the chainrings on the power2max NG
eco
power meter. In the process, take
care that they are aligned correctly and solidly attached in accordance with the respecti-
ve manufacturer’s specifications. Guide the large chainring from above onto the power-
2max NG
eco
power meter.
Step 2
Align the holes for the bolts.
Step 3
After you have guided the small chainring onto the power2max NG
eco
power meter from
the rear, tighten everything with the dedicated chainring bolts.
IMPORTANT:
Observe the torque values prescribed by the manufacturer.
Pay attention to the alignment of the chainrings and bolts.
Please adhere to the manufacturer’s specifications.
Step 4
Then mount the right crankarm to the power2max NG
eco
power meter. Guide the right cran-
karm from the front through the opening in the power meter. Pay attention to the align-
ment and the correct fitting of the crankset to the power meter. For models with lockrings
like FSA BB386EVO: place a few drops of medium-strength threadlock (e.g. Loctite 243)
on the inner side of the lockring and tighten it with the help of the lockring tool.
IMPORTANT:
Please pay attention that the lockring is correctly seated on the threads.
Lock the lockring tool into a vice. This guarantees that the lockring tool is secure and
stable for further installation: tighten the lockring to the prescribed torque values. You
can also find these values in the download area on w w w . power2m ax . c om or ask the
crankset manufacturer.
Bei Modellen mit Montage durch Schrauben (z. B., FSA Megaexo, SRAM Force22/S900):
Geben Sie einen Tropfen mittelfeste Schraubensicherung auf die Montageschrauben. Wenn
diese von Werk bereits mit Schraubensicherung beschichtet sind, müssen Sie dies nicht
tun. Ziehen Sie die Montageschrauben mit dem vorgegebenen Anzugsmoment fest. Anzugs-
momente finden Sie ebenfalls im Downloadbereich auf w ww . pow er2ma x . com .
power2max NG
Eco
22
English

Power2max NGeco Specifications

Battery

battery life	400 hours
battery charge indicator	3 x green: 60 - 100%, 2 x green: 40 - 60%, 1 x green: 20 - 40%, 1 x red short: 10 - 20%, 1 x red long: 0 - 10%

Transmission and Accuracy

transmission standards	ANT+ Power Only Profile
accuracy	±2%
transmitted data	Power, Cadence

Measurement Range

power range	10 - 2999 W
torque range	0 - 250 Nm
cadence range	30 - 250 RPM
