27
Your rear roller cylinder mower is fitted with a moulded plug;
however, if you need to replace a fitted plug then follow the
instructions below.
IMPORTANT
The wires in the mains lead are coloured in accordance with the
following code:
Blue - Neutral / Brown - Live
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The blue wire must be connected to the terminal marked ‘N’ or
coloured black.
The brown wire must be connected to the terminal marked ‘L’ or
coloured red.
If a 13AMP (BS1363/A) plug is used, a 13A fuse must be fitted. If any
other type of plug is used, a 13AMP fuse must be fitted, either in
the plug or adaptor, or on the distribution board.
Note: If a moulded plug is fitted and has to be removed, take
great care in disposing of the plug and severed cable; it must be
destroyed to prevent engaging into a socket. If the supply cord
is damaged it must be replaced by a service agent or a similarly
qualified person in order to avoid hazard.
Plug Replacement
Replacing the Plug
3. Protect the product from any heavy impact or strong vibrations
which may occur during transportation in vehicles.
4. Secure the product to prevent it from slipping or falling over.
