17
Step 1 - Assemble the lower handles
Preparing to assemble the Rear Roller
Cylinder Mower
Assembly
1. Remove all parts of the rear roller cylinder mower from the box
and carefully remove all packaging. Take care not to lose any
instructions which may be attached to the parts. These provide
important information, which will be required while assembling
the rear roller cylinder mower.
2. Keep all packaging until the rear roller cylinder mower is fully
assembled and has been operated successfully.
Note: Please keep original packaging for warranty purposes.
Position the lower handle into the slot on the deck and tighten the
fixing screws on both sides.
Note: Make sure that the cable hooks are at the back side of the
machine.
