PowerBase 577179 - Steps 2 & 3: Handles and Cord

18
Step 2 - Assembling the middle and upper
handles
1. Slide the cord retainer onto the middle handle, sliding it around
to the top of the handle so it does not fall off during the
following assembly steps.
2. Slide the middle handle into the profiled area of the lower
handle frame. Make sure that the holes of both sides of the
upper handle are directly aligned with the holes of the frame.
3. Secure the upper handle to the middle handle frame with the
CAM lever and bolts provided.
4. Repeat the above process on the upper and lower handle.
Note: Make sure that the switch box is on the same side as the
cable from the deck and that they are not twisted.
1. Secure the power cable to the frame using the cable clips. Use
one clip on the middle handle frame and the second on the
lower handle frame.
Step 3 - Securing the power cord with
cable clips
