www.powerbox-systems.com 27
10. INPUT MAPPING
The Input Mapping menu is used to assign the channels coming from the transmit-
ter to functions such as Gyro, Sequencer or capacity reset.
The assignment process is carried out by the Setup Assistant and the Sequencer
Assistant. If you add functions later, or change channels at the transmitter, it is pos-
sible to make appropriate adjustments subsequently at any time.
In particular, assigning different Gain channels for the iGyro makes it easier to enter
the settings for more complex applications.
These pictures also clearly show the separate Gain channels for each gyro function.
For example, aileron, elevator and rudder can be assigned three different Gain chan-
nels, which can then be adjusted individually in a single test-ight.
To assign a channel, use buttons I and II to select the function, then press the SET
button. You now have two options for choosing the channel:
a) Use buttons I and II
b) Simply move the transmitter stick: the channel is automatically detected. If
more than one channel is assigned to a particular transmitter control (for ex
ample, channels 2 and 6 for aileron control), repeatedly move the stick briey
from centre until the desired channel is selected.
Press the SET button to conrm your choice.
