Technical Specifications
All electrical specifications are given for an impedance of 1000 Ω per channel.
Battery: 2x Lithium Polymer (LiPo) rechargeable 3.7 V, 210 mAh
Charging Input: 5V through USB Type C connection (custom USB charging cable is provided as part of
the package), I/P rating: 5Vdc 1-2.1A
Stimulation Channels: 2 independent, optically isolated
Stimulation Waveform: Bi-phasic rectangular with zero mean (under load)
Supported Stimulation Frequency Range: 1-150 Hz
Supported Stimulation Pulse Width: 32-416 µs (for main/positive phase)
Maximum output voltage/amperage: 130 V/130 mA (+-5%)
Bluetooth: Built-in Bluetooth Low Energy 4.0
Electro-compatibility (EMC): ETSI EN 301 489-1/EN 301 489-17/EN 50385/EN 55011/IEC 60601-1-2
C RF Data:
Operating Frequency Range: 2402 MHz-2480 MHz (ISM range)
Modulation Type: GFSK with AFH
Peak Transmit Power: -15.86dBm (0.026 mW)
Channel Spacing/Number of Channels: 2 MHz, 40 channels (3 for advertising, 37 for data)
Antenna Type: PCB Antenna, 2 dBi (1.58 mW) gain
Mobile Application Compatibility:
Android 5.0 Lollipop (or later) powered smart phone with Bluetooth Smart Ready compatibility
and High Definition (or better) touch screen
Apple iPhone 4S/iPod 5
th
Gen/iPad 3
rd
Gen or newer smart phone/tablet powered by iOS 9.0 (or
later)
Device Dimensions: 55x55x13.6 mm
Device Weight: 30 g
Environment Specifications:
Operating/Storage/Transport: Temperature from 0 C to +40 C
Humidity: 10-90% RH
Atmospheric pressure: from 700 hPa to 1060 hPa
Product Expected Lifetime: 5 years
Housing: ABS & TPU
