Copyright © 2022-2023 PowerFlex Systems, Inc. All Rights Reserved. 18
Electrical
Input voltage
208-240VAC +/- 5 percent
Frequency
50-60Hz
Rated output current
48A (60A, 2-pole breaker)
40A (50A, 2-pole breaker)
32A (40A, 2-pole breaker)
16A (20A, 2-pole breaker)
Power output
1.6-11.5kW
Environmental
Storage temperature
-40°F to 158°F / -40°C to 70°C
Operation temperature
-22°F to 122°F / -40°C to 50°C
Relative humidity
Up to 95% RH non-condensing
Enclosure
IK08, IP65, NEMA 3R
Installation
Indoor and outdoor, no ventilation required
Dimension and weight
Product dimensions
13.8" H x 10.1" W x 4.2" D (351 x 257 x 107 mm)
Cable length
18ft (5.48 m) (standard) or 25ft (7.62 m) (fleet option only)
Net weight
17.2 lbs (7.8 kg) 18ft model
Standard and safety
Charging interface
SAE J1772 type 1
Safety compliance
UL 2594, UL 2231-1/-2, CSA C22.2 no 280, FCC part 15
Protection features
UVP, OVP, RCD (CCID 20), SPD, Ground Fault Protection OCP, OTP, Control Pilot Fault
Protection
Connectivity
User authentication
RFID (ISO 14443)
Communication protocol
OCPP 1.6 J
Networking
LAN, Wi-Fi (802.11 b/g/n)
