Powermate WX5400 User Manual

4 Owner’s Manual for Portable Generator
Section 2 General Information and Setup
Figure 2-1. Features and Controls
TABLE 1. Generator Components
Figure 2-2. Control Panel
001615
8
7
13
10
12
9
11
1 120 Volt AC, 20 Amp Duplex Receptacle
2 120/240 Volt AC, 30 Amp Locking
Receptacle (NEMA L14-30R)
3 Circuit Breakers (AC)
4 On/Off Switch
5 Hour Meter
6 Ground Terminal
7 Choke Lever
8 Fuel Tank
9Oil Drain
10 Oil Fill
11 Air Cleaner
12 Recoil Handle
13 Fuel Shutoff Valve
001616
3
5
1
4
2
6

Powermate WX5400 Specifications

General

Brand	Powermate
Model	WX5400
Category	Portable Generator
Language	English
