Manual#: 851-000134
Version 3.4 – 08/11/2022
5.2.2 GPS-R — LED Indications
5.2.3 PM1/PM2 — LED Indications
Green = AC input power detected
Blue = 24V auxiliary outputs are ON (PM2 only)
Green = PPS pulse (blinks at 1Hz)
