POWERSIDE PQube 3 User Manual

Page 45 of 49
Manual#: 851-000134
Version 3.4 – 08/11/2022
Event Type/Name
Description
Threshold
Default
Min/Max
Threshold
Current events
Phase Over Current Trigger
I1/I2/I3/.. /I8 channels(*)
RMS amplitude exceeds threshold
1 A
0.0001 A to no
limit
Phase Under Current Trigger
I1/I2/I3/.. /I8 channels(*)
RMS amplitude falls below threshold
0 A
0.0001 A to no
limit
Phase Current Trigger
I1/I2/I3/.. /I8 channels(*)
Inrush (current gradient) exceeds a gradient
threshold
1 A
1 cycle
0.0001 A to no limit
1 cycle to no limit
Note: (*) 8 channels for PQube 3, 14 channels for PQube 3e
Analog channels Events
AN1/2/3/4 Sag
Analog Channel AN1 through AN4-E Sag
(method as per IEC61000-4-30 Ed3)
2 V
No limits
AN1/2/3/4 Swell
Analog Channel AN1 through AN4-E Swell
(method as per IEC61000-4-30 Ed3)
60 V
No limits
ENVIROSENSOR events
Probe A/B
Undertemperature
Temperature below the lower threshold
0º C
No limits
Probe A/B Overtemperature
Temperature above the upper threshold
50º C
No limits
Probe A/B Low Humidity
Humidity below the lower threshold
0%
No limits
Probe A/B High Humidity
Humidity above the upper threshold
90%
No limits
