16
5.2.6 Rear Board Layout
Colour Description
Load Setting Switches
Audio Input Connectors
Remote Level Connectors
Alarm Connectors
Layout
Colour Description
CH Level Potentiometers
LEDs Panel
Layout
5.2.7 Front Board Layout
Quattrocanali (4CH)
Duecanali (2CH)
Quattrocanali (4CH)
Duecanali (2CH)
QUATTROCANALI | SERVICE MANUAL
