3
PRODUCT SPECIFICATIONS:
BOX CONTENTS:
Input Voltage: 220-240 V AC ~ 50Hz, 3.6A
Reverse current*: < 10 mA (no AC input)
Nominal output voltage: 12 VDC / 24 VDC / 12.8 VDC / 13.6 VDC
Nominal output current: 26 A / 13 A / 26 A / 5.0 A
Charging voltage: 14.4V / 14.8V for 12V battery, 28.8 V /
29.6V for 24V battery, 14.4V for Lithium
(12.8V 4-cells LiFePO4), 19.6V for 16V
AGM, 19V for 16V Lithium (16V 4-cells
LiFePO4), and 13.6V for SMPS
Charging current: ±10% for 26A/13A/10A/5A/2.6A
±20% for 1.3A
Battery type: 12V lead-acid battery 50Ah - 500Ah
16V AGM battery 25 Ah - 250 Ah
24V lead-acid battery 25 Ah - 250Ah
Lithium (12.8V 4-cells LiFePO4):
capacity of 30 - 200Ah
Lithium (16V 4-cells LiFePO4):
capacity of 25 - 250Ah
Housing protection type: IP 20
Safety class: II
*Reverse current is the current used by the charging station battery, when
no mains current is connected.
Check the appliance and all accessories for damage immediately after
unpacking. Do not put a defective appliance or parts into operation.
• MB3912 Charger
• Clamps Cable
• Eyelet M10 Cable
• Instruction Manual
