PowerTech MP3745 User Manual

7


III.DescriptionofLCDscreen:
ABCDEFG


HIJKLMNOP
A.Sunicon,displayedwhensolarpanelisconnected.
B.Sunlighticon,8intotal,displayaccordingtothechargingcurrent
C.MPPTiconindicatestheMPPTcharger.
D.WIFIicon;turnonWIFIthroughbuttonsettings,readproductdataandcontrolloadoutput
throughAPP.
E.Remotecontrolicon;displayed
whentheremotecontrolisconnected(remotecontrol
optional).
F.Settingsicon;turnonwhenenteringthesettingparameters,andturnoffwhenexit.
D.WIFIicon;WIFION/OFFoptional,defaultON.
F.Batterylevelicon;displaythecorrespondingiconaccordingtothebatteryvoltage.
I.Loadicon;turnon
whentheloadisturnedon,synchronizedwiththeloadswitchON.
J.Connector,three,upcorrespondingtoPV,middlecorrespondingtobattery,down
correspondingtoload.
K.Currentlyidentifiedbatterytype(12/24/36/48V).
L.Protectionicon.Whenthisiconappears,itindicatesthatthemachinehassomeprotection,
suchasload
overcurrent,shortcircuitprotection,undervoltageprotection,etc.(Refertothefault
code).
M.Loadtimingclock2.
N.Loadtimingclock1.

PowerTech MP3745 Specifications

General

Brand	PowerTech
Model	MP3745
Category	Controller
Language	English
