26 GTS Series Uninterruptible Power Manager
User Replaceable Battery
NOTE:
Changing the batteries in this UPM is designed to be a safe and
simple procedure. Batteries may be replaced while the UPM
is on and providing power to the connected load. You should
remember that if a power outage occurs after the old batteries are
disconnected and before the new batteries are installed, power will
be lost to your connected system and components.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE.
When replacing batteries, replace with the same number of the following
battery.
Brand Type Rating
Yuasa REW45-12 12V8Ah
Yuasa NPX35 12V8Ah
Yuasa RE7-12H 12V7Ah
Yuasa NPW45-12 12V8.5Ah
Yuasa NP7-12 12V7Ah
CSB GP1272 12V7.2Ah
CSB HR1234 12V8.5Ah
CAUTION
Risk of Energy Hazard, 12V, maximum 8.5 Ampere-hour battery. Before
replacing batteries, remove conductive jewelry such as chains, wrist
watches, and rings. High energy through conductive materials could
cause severe burns.
