User manual PowerXtreme X20/X30
E18-X20X30-EN00 www.emergoplus.com Page 16 of 25
connections securely. Recommended tightening torque for M6 is
9.9 - 14 Nm. Do not use too great a tightening torque, as this can
lead to irreparable damage to the LiFePO4 battery.
▪ If you use screws to connect consumers instead of the supplied
battery terminals, make sure that these screws are not longer than
10mm.
▪ Connect the negative pole of the battery to the negative connection
of the caravan mover unit.
▪ Connects the positive terminal of the battery to the positive
terminal of the caravan mover unit.
▪ Use cables as prescribed in your caravan mover manual. It is
recommended to use a minimum of 16 mm2. Use one red wire for
the + and one black or blue wire for the -.
CAREFUL!
If bolts that are too long are used, the connections
will not get stuck! This leads to large contact
resistances and can cause the battery or equipment
to spark or switch off.
