Powrmatic LX Series User Manual

page no. 10 of 68
LX Range Users, Installation & Servicing Instructions Doc Ref M110 issue 1.0 Dec 2020.
Dimensions
LX C- Centrifugal Close Coupled Fan Units
Model 15 20 25 30 35 40 50 60 70 90 120 140
A
mm
997 997 997 997 1325 997 1325 1325 1325 1950 1950 1950
B
mm
730 730 730 730 819 730 819 819 819 819 819 819
C
mm
450 500 570 670 532 720 684 760 912 810 975 1140
DØ
mm
80 80 80 100 100 100 100 130 130 130 130 130
E
mm
268 268 268 268 357 268 357 357 357 337.5 337.5 337.5
F
mm
200 248 318 396 170 446 320 325 476 457 622 787
G
mm
120 120 120 142 142 142 142 220 220 220 220 220
H
mm
317 317 317 317 347 317 347 347 347 347 347 347
J
mm
450 450 450 450 700 450 700 700 700 662.5 662.5 662.5
K
mm
230 230 230 230 278 230 278 278 278 278 278 278
L
mm
1160 1205 1205 1275 1365 1275 1450 1450 1450 1365 1450 1450
M
mm
217.5 217.5 217.5 217.5 247.5 217.5 247.5 237 237 247 247 247
N
mm
117 117 117 117 145.5 117 145.5 145.5 145.5 90 90 90
P
mm
185 172 245 219.5 144 285 221.5 298 373.5 412 413 481
R
mm
137 137 137 137 181.5 137 181.5 181.5 181.5 181.5 181.5 181.5
S
mm
630 630 630 630 927 630 927 927 927 1552 1552 1552
T
mm
376 446 516 616 478 666 631 707 858 757 922 1087
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
"Title Here"
LX CCF - Centrifugal Close Coupled Fan Units
SCALE: 1:12.5SHEET 1 OF 1
"Description Here"
"Material Gauge & Spec Here"
ISSMODIFICATIONSDATEDCRI/ADRN
UNSPEC. TOLS.
Hole centers
±0.1mm
General ±0.1mm
Finished sizes ±0.1mm
MM
DO NOT SCALE
This drawing is copyright and the property of POWRMATIC
LIMITED. It must not be used without their knowledge, nor
communicated to any other person or company.
Powrmatic Ltd. Hortbridge, Ilminster. Somerset.
TA19 9PS.
Tel: 01460 53535 Fax: 01460 52341
Web: www.powrmatic.co.uk E mail: r&d@powrmatic .co.uk
POWRMATIC LTD
01
NEW DRAWING06/01/2021
--
CB
TITLE:
DESCRIPTION:
DRAWING NUMBER:
MATERIAL GAUGE & SPEC:
SALVAGNINI:
MATERIAL REQUIRED:
PROJECTION:
UNITS:
S
T
A
C
B
L
N
P
GAS ENTRY POINT
K
J CRS
H
R
2
2
8
.
0
C
R
S
2
2
8
.
0
C
R
S
R
SUSPENSION POINTS M10
E
G
M
R
2
2
8
.
0
C
R
S
2
2
8
.
0
C
R
S
R
K H
J CRS J CRS
SUSPENSION POINTS M10
35.0 50.0
ELEC ENTRY
1
9
7
.
0
F
G


D
M
E
G
Important: Please refer to section 1.3.7.1 for ducting requirements
