page no. 9 of 68
LX Range Users, Installation & Servicing Instructions Doc Ref M110 issue 1.0 Dec 2020.
Dimensions
LX V - Axial Fan Downflow
Model 15 20 25 30 35 40 50 60 70 90 120 140
A
mm
997 997 997 997 1325 997 1325 1325 1325 1950 1950 1950
B
mm
730 730 730 730 819 730 819 819 819 819 819 819
C
mm
450 500 570 670 532 720 684 760 912 810 975 1140
DØ
mm
80 80 80 100 100 100 100 130 130 130 130 130
E
mm
268 268 268 268 357 268 357 357 357 337.5 337.5 337.5
F
mm
200 248 318 396 170 446 320 325 476 457 622 787
G
mm
120 120 120 142 142 142 142 220 220 220 220 220
H
mm
289.5 289.5 289.5 289.5 319.5 289.5 319.5 319.5 319.5 319.5 319.5 319.5
J
mm
260 260 260 260 385 260 385 385 385 460 460 460
K
mm
202.5 202.5 202.5 202.5 250.5 202.5 250.5 250.5 250.5 250.5 250.5 250.5
L
mm
875 885 835 850 934 850 954 929 929 954 929 929
M
mm
217.5 217.5 217.5 217.5 247.5 217.5 247.5 237 237 247 247 247
N
mm
117 117 117 117 145.5 117 145.5 145.5 145.5 90 90 90
P
mm
185 172 245 219.5 144 285 221.5 298 373.5 412 413 481
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
E E
F F
"Title Here"
LX V - Axial Fan Downflow Units
SCALE: 1:12SHEET 1 OF 1
"Description Here"
"Material Gauge & Spec Here"
ISSMODIFICATIONSDATEDCRI/ADRN
UNSPEC. TOLS.
Hole centers
±0.1mm
General ±0.1mm
Finished sizes ±0.1mm
MM
DO NOT SCALE
This drawing is copyright and the property of POWRMATIC
LIMITED. It must not be used without their knowledge, nor
communicated to any other person or company.
Powrmatic Ltd. Hortbridge, Ilminster. Somerset.
TA19 9PS.
Tel: 01460 53535 Fax: 01460 52341
Web: www.powrmatic.co.uk E mail: r&d@powrmatic .co.uk
POWRMATIC LTD
01
NEW DRAWING06/01/2021
--
CB
TITLE:
DESCRIPTION:
DRAWING NUMBER:
MATERIAL GAUGE & SPEC:
SALVAGNINI:
MATERIAL REQUIRED:
PROJECTION:
UNITS:
A
E
G
D
C
+
3
0
C
+
3
0
K
J CRS J CRS
H
N
P
DROP ROD
SUSPENSION POINTS M10
ELEC ENTRY
GAS ENTRY POINT
K
J CRS J CRS J CRS
H
N
M
P
F
G
ELEC ENTRY
GAS ENTRY POINT
DROP ROD
SUSPENSION POINTS M10
B
+
6
5
A
B
L
C
M
50.0
1
9
7
.
0
50.0
1
9
7
.
0
F
G
M
