10 / 16
F7.16
Forward/reverse rotation deadband
0.00s to 3600.0s
0.00s
F7.17
Reverse rotation control
0:Allow ;
1:Prohibit
0
F7.18
Set frequency lower than lower
limit frequency mode
0:Running at lower limit frequency;
1:Stop;
2:Zero speed running
0
F7.19
Droop control
0.00Hz to 10.00Hz
0.00Hz
F7.20
Setting cumulative power-on arrival
time
0h to 36000h
0h
F7.21
Setting cumulative running arrival
time
0h to 36000h
0h
F7.22
Start protection
0:OFF;
1:ON
0
F7.23
Frequency detection value (FDT1)
0.00Hz to F0.19(Maximum frequency)
50.00Hz
F7.24
Frequency detection hysteresis value
(FDT1)
0.0% to 100.0%(FDT1 level)
5.0%
F7.25
Frequency reaches detection width
0.00 to 100%(Maximum frequency)
0.0%
F7.26
Frequency detection value (FDT2)
0.00Hz to F0.19(Maximum frequency)
50.00Hz
F7.27
Frequency detection hysteresis value
(FDT2)
0.0% to 100.0%(FDT2 level)
5.0%
F7.28
Random arrivals frequency
detection value 1
0.00Hz to F0.19(Maximum frequency)
50.00Hz
F7.29
Random arrivals frequency
detection width 1
0.0% to 100.0%(maximum frequency)
0.0%
F7.30
Random arrivals frequency
detection value 2
0.00Hz to F0.19(Maximum frequency)
50.00Hz
F7.31
Random arrivals frequency
detection width 2
0.0% to 100.0%(Maximum frequency)
0.0%
F7.32
Zero current detection level
0.0% to 300.0%(Rated motor current)
5.0%
F7.33
Zero current detection delay time
0.01s to 360.00s
0.10s
F7.34
Overrun value of output current
0.0%(not detected);0.1% to 300.0%
(Rated motor current)
200.0%
F7.35
Output Current overrun detection
delay time
0.00s to 360.00s
0.00s
F7.36
Random arrivals current 1
0.0% to 300.0%(Rated motor current)
-100.0%
F7.37
Random arrivals current 1 width
0.0% to 300.0%(Rated motor current)
0.0%
F7.38
Random arrivals current 2
0.0% to 300.0%(Rated motor current)
-100.0%
F7.39
Random arrivals current 2 width
0.0% to 300.0%(Rated motor current)
0.0%
F7.40
Module temperature arrival
0 to 100
75
F7.41
Cooling fan control
0:Fan running only when running
1:Fan always running
0
F7.42
Timing function selection
0:Invalid
1:Valid
0
F7.43
Timing run time selection
0:F7.44setting;
1: Analog AI1;
3: Panel potentiometer
Note:Analog input range 100%
corresponds to F7.44
0
F7.44
Timing run time
0.0Min to 6500.0Min
0.0Min
F7.45
Current running arrival time.
0.0Min to 6500.0Min
0.0Min
F7.46
Awakens frequency
Dormancy frequency(F7.48) to
maximum frequency(F0.19)
0.00Hz
F7.47
Awakens delay time
0.0s to 6500.0s
0.0s
F7.48
Dormancy frequency
0.00Hz to awakens frequency(F7.46)
0.00Hz
F7.49
Dormancy delay time
0.0s to 6500.0s
0.0s
F7.50
AI1 input voltage protection lower
limit
0.00V to F7.51
3.1V
F7.51
AI1 input voltage protection upper
limit
F7.50 to 10.00V
6.8V
F8 group Fault and protection parameter group
Code
Parameter name
Setting range
Factory
setting
Chan
ge
F8.00
Overcurrent stall gain
0 to 100
20
F8.01
Overcurrent stall protection current
100% to 200%
-
F8.02
Motor overload protection
0:Prohibit;
1:Allow
1
F8.03
Motor overload protection gain
0.20 to 10.00
1.00
F8.04
Motor overload pre-alarm coefficient
50% to 100%
80%
F8.05
Overvoltage stall gain
0 to 100
0
F8.06
Overvoltage stall protection voltage
/ energy consumption brake voltage
120% to 150%
130%
F8.08
Output phase loss protection selection
0:Prohibit;
1:Allow
1
F8.09
Power-on short circuit to ground
0:Invalid;
1:Valid
1
F8.10
Number of automatic fault reset
0 to 32767
0
F8.11
Fault DO action selection during
automatic fault reset
0:OFF;1:ON
0
F8.12
Automatic fault reset interval
0.1s to 100.0s
1.0s
F8.25
Abnormal reserve frequency
60.0% to 100.0%
100%
F8.26
Momentary power cut action
selection
0:Invalid;
1:Deceleration;
2:Deceleration and stop
0
F8.28
Recovery voltage judgment time of
momentary power cut
0.00s to 100.00s
0.50s
F8.29
Judgment voltage of momentary
power cut
50.0% to 100.0%(Standard bus voltage)
80%
