Powtran PI500A Series User Manual

9 / 16
F5 group Vector control parameter group
Code
Parameter name
Setting range
Factory
setting
Chan
ge
F5.00
Speed loop ratio G1
1 to 100
30
☆
F5.01
Speed loopintegral T1
0.01s to 10.00s
0.50s
☆
F5.02
Switching frequency 1
0.00 to F5.05
5.00Hz
☆
F5.03
Speed loop ratio G2
0 to 100
20
☆
F5.04
Speed loop integral T2
0.01s to 10.00s
1.00s
☆
F5.05
switching frequency 2
F5.02 to F0.19(Max. frequency)
10.00Hz
☆
F5.06
Speed loop integral
0:Valid
1:Invalid
0
☆
F5.07
Torque limit upper limit source
0: Function code F5.08 setting;
1: Analog AI1 setting;
3: Panel potentiometer setting;
4: High speed pulse setting;
5:Communication settings;
0
☆
F5.08
Upper limit digital setting for torque
0.0% to 200.0%
150.0%
☆
F5.09
Vector control differential gain
50% to 200%
150%
☆
F5.10
Speed loop filter time constant
0.000s to 0.100s
0.000s
☆
F5.11
Vector control overexcitation gain
0 to 200
64
☆
F5.12
Excitation regulator proportional gain
0 to 60000
2000
☆
F5.13
Excitation regulator integral gain
0 to 60000
1300
☆
F5.14
Torque regulator proportional gain
0 to 60000
2000
☆
F5.15
Torque regulator integral gain
0 to 60000
1300
☆
F6 group Keyboard and display parameter group
Code
Parameter name
Setting range
Factory
setting
Chan
ge
F6.00
STOP/RESET key functions
0: STOP/RES key is enabled only under keyboard
operation mode
1:STOP/RES key is enabled under any operation
mode
1
☆
F6.01
Running status display
parameters 1
0x0000 to 0xFFFF
001F
☆
F6.02
Running status display
parameters 2
0x0000 to 0xFFFF
0000
☆
F6.03
Stop status display
parameters
0x0001 to 0xFFFF
0033
☆
F6.04
Load speed display coefficient
0.0001 to 6.5000
3.0000
☆
F6.05
Decimal places for load
speed display
0:0 decimal places
2:2 decimal places
1:1 decimal places
3:3 decimal places
1
☆
F6.06
Inverter module radiator
temperature
0.0℃ to 100.0℃
-
●
F6.07
Total run time
0h to 65535h
-
●
F6.08
Total power-on time
0h to 65535h
-
●
F6.09
Total power consumption
0 to 65535kWh
-
●
F6.10
Product series number
Frequency inverter series number
-
●
F6.11
Software version number
Control board software version
-
●
F6.17
Power correction coefficient
0.00 to 10.00
1.00
☆
F6.20
Keypad lock selection
0:RUN, STOP button valid
2: RUN, STOP, UP, DOWN button valid
3: STOP button valid
Note: Keyboard potentiometers are not limited by
this function
0
☆
F6.21
QUICK key function
selection
0: No function;
1: Jog running
2: Shift switch display state;
3: FWD/RVS switchover
4: Clear-up UP/DOWN setting
5: Free stop; 6: running command given in
sequence
1
☆
F7 group Auxiliary functional parameters group
Code
Parameter name
Setting range
Factory
setting
Chan
ge
F7.00
Jog running frequency
0.00Hz to F0.19(Maximum frequency)
6.00Hz
☆
F7.01
Jog acceleration time
0.0s to 6500.0s
5.0s
☆
F7.02
Jog deceleration time
0.0s to 6500.0s
5.0s
☆
F7.03
Jog priority
0:Invalid;1:Valid
1
☆
F7.04
Jump frequency 1
0.00Hz to F0.19(Maximum frequency)
0.00Hz
☆
F7.05
Jump frequency 2
0.00Hz to F0.19(Maximum frequency)
0.00Hz
☆
F7.06
Jump frequency range
0.00Hz to F0.19(Maximum frequency)
0.00Hz
☆
F7.07
Jump frequency availability during
ac/deceleration process
0:Invalid;
1:Valid
0
☆
F7.08
Acceleration time 2
0.0s to 6500.0s
Depends on
models
☆
F7.09
Deceleration time 2
0.0s to 6500.0s
Depends on
models
☆
F7.10
Acceleration time 3
0.0s to 6500.0s
Depends on
models
☆
F7.11
Deceleration time 3
0.0s to 6500.0s
Depends on
models
☆
F7.12
Acceleration time 4
0.0s to 6500.0s
Depends on
models
☆
F7.13
Deceleration time 4
0.0s to 6500.0s
Depends on
models
☆
F7.14
Switching frequency point between
acceleration time 1 and acceleration
time 2
0.00Hz to F0.19(Maximum frequency)
0.00Hz
☆
F7.15
Switching frequency point between
deceleration time 1 and
deceleration time 2
0.00Hz to F0.19(Maximum frequency)
0.00Hz
☆
