11 / 16
F9 group Communication parameter set
Code
Parameter name
Setting range
Factory
setting
Chan
ge
F9.00
Baud rate
Units digit:Modbus
2:1200BPS;
3:2400BPS;
4:4800BPS;
5:9600BPS
6:19200BPS;
7:38400BPS;
8:57600BPS;
9:115200BPS
Tens digit:Reserved ;
Hundreds digit: Reserved;
Thousands digit:Reserved
6005
F9.01
Data format
0:No parity(8-N-2);
1:Even parity(8-E-1)
2:Odd parity(8-O-1)
3:No parity(8-N-1)
0
F9.02
This unit address
1 to 250,0 for broadcast address
1
F9.03
Response delay
0ms to 20ms
2ms
F9.04
Communication timeout time
0.0(Invalid);0.1 to 60.0s
0.0
F9.05
Data transfer format selection
Units digit:Modbus
0:Non-standard MODBUS protocol;1:Standard
MODBUS protocol
Tens digit:Profibus-DP
0:PPO1 format;1:PPO2 format;2:PPO3
format;3:PPO5 format
31
F9.06
Communication read current
resolution
0:0.01A ;1:0.1A
0
F9.07
Communication card type
0:Modbus communication card
0
Fb group Control optimization parameter group
Code
Parameter name
Setting range
Factory
setting
Chan
ge
Fb.00
Fast current limiting manner
0:Disable;
1: Enable
1
Fb.01
Undervoltage point setting
50.0% to 140.0%
100.0%
Fb.02
Overvoltage point setting
200.0 to 2500.0V
-
Fb.03
Deadband compensation
mode selection
0:No compensation;
1:Compensation mode 1;
2:Compensation mode 2
1
Fb.04
Current detection compensation
0 to 100
5
Fb.05
Vector optimization without
PG mode selection
0:No optimization;
1:Optimization mode 1;
2:Optimization mode 2
1
Fb.06
Upper limiting frequency for
DPWM switching
0.00 to 15.00Hz
12.00Hz
Fb.07
PWM modulation method
0:Asynchronous;
1:Synchronous
0
Fb.08
PWM modulation manner
0:Invalid
1 to 10:PWM carrier frequency random depth
0
E0 group Pendulum frequency, fixed length and counting parameter array
Code
Parameter name
Setting range
Factory
setting
Chan
ge
E0.00
Swing setting mode
0:Relative to center frequency;
1:Relative to maximum requency
0
E0.01
Wobbulate range
0.0% to 100.0%
0.0%
E0.02
Sudden jump frequency range
0.0% to 50.0%
0.0%
E0.03
Wobbulate circle
0.1s to 3000.0s
10.0s
E0.04
Triangle wave rise time coefficient
0.1% to 100.0%
50.0%
E0.05
Set length
0m to 65535m
1000m
E0.06
Actual length
0m to 65535m
0m
E0.07
Pulse per meter
0.1 to 6553.5
100.0
E0.08
Set count value
1 to 65535
1000
E0.09
Specified count value
1 to 65535
1000
E1 group Multi-section instruction and simple PLC parameter set
Code
Parameter name
Setting range
Factory
setting
Chan
ge
E1.00
0-stage speed setting 0X
-100.0% to 100.0%
0.0%
E1.01
1-stage speed setting 1X
-100.0% to 100.0%
0.0%
E1.02
2-stage speed setting 2X
-100.0% to 100.0%
0.0%
E1.03
3-stage speed setting 3X
-100.0% to 100.0%
0.0%
E1.04
4-stage speed setting 4X
-100.0% to 100.0%
0.0%
E1.05
5-stage speed setting 5X
-100.0% to 100.0%
0.0%
E1.06
6-stage speed setting 6X
-100.0% to 100.0%
0.0%
E1.07
7-stage speed setting 7X
-100.0% to 100.0%
0.0%
E1.08
8-stage speed setting 8X
-100.0% to 100.0%
0.0%
E1.09
9-stage speed setting 9X
-100.0% to 100.0%
0.0%
E1.10
10-stage speed setting 10X
-100.0% to 100.0%
0.0%
E1.11
11-stage speed setting 11X
-100.0% to 100.0%
0.0%
E1.12
12-stage speed setting 12X
-100.0% to 100.0%
0.0%
E1.13
13-stage speed setting 13X
-100.0% to 100.0%
0.0%
E1.14
14-stage speed setting 14X
-100.0% to 100.0%
0.0%
E1.15
15-stage speed setting 15X
-100.0% to 100.0%
0.0%
E1.16
Simple PLC running mode
0: Stop after single running
1: Hold final value after single running
2: Circulating
0
E1.17
Simple PLC power-down memory
selection
Units digit: power-down memory
selection
0: Power-down without memory
1: Power-down with memory
11
