Tens digit: Stop memory selection
0: Stop without memory
1: Stop with memory
E1.18
0 stage running time T0
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.19
0 stage ac/deceleration time selection
0:F0.13, F0.14;
1:F7.08, F7.09;
2:F7.10, F7.11;
3:F7.12, F7.13
0
E1.20
1 stage running time T1
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.21
1 stage ac/deceleration time selection
Same as E1.19
0
E1.22
2 stage running time T2
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.23
2 stage ac/deceleration time selection
Same as E1.19
0
E1.24
3 stage running time T3
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.25
3 stage ac/deceleration time selection
Same as E1.19
0
E1.26
4 stage running time T4
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.27
4 stage ac/deceleration time selection
Same as E1.19
0
E1.28
5 stage running time T5
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.29
5 stage ac/deceleration time selection
Same as E1.19
0
E1.30
6 stage running time T6
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.31
6 stage ac/deceleration time selection
Same as E1.19
0
E1.32
7 stage running time T7
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.33
7 stage ac/deceleration time selection
Same as E1.19
0
E1.34
8 stage running time T8
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.35
8 stage ac/deceleration time selection
Same as E1.19
0
E1.36
9 stage running time T9
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.37
9 stage ac/deceleration time selection
Same as E1.19
0
E1.38
10 stage running time T10
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.39
10 stage ac/deceleration time selection
Same as E1.19
0
E1.40
11 stage running time T11
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.41
11 stage ac/deceleration time selection
Same as E1.19
0
E1.42
12 stage running time T12
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.43
12 stage ac/deceleration time selection
Same as E1.19
0
E1.44
13 stage running time T13
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.45
13 stage ac/deceleration time selection
Same as E1.19
0
E1.46
14 stage running time T14
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.47
14 stage ac/deceleration time selection
Same as E1.19
0
E1.48
15 stage running time T15
0.0s(h) to 6500.0s(h)
0.0s(h)
E1.49
15 stage ac/deceleration time selection
Same as E1.19
0
E1.50
Simple PLC run-time unit
0: S (seconds) 1: H (hours)
0
E1.51
Multi-stage command 0 reference
manner
0: Function code E1.00 reference
1: Analog AI1 reference
3: Panel potentiometer setting
4: High-speed pulse setting
5: PID control setting
6:Keyboard set frequency (F0.01) setting,
UP/DOWN can be modified
0
E2 group PID functional parameter group
Code
Parameter name
Setting range
Factory
setting
Change
E2.00
PID setting source
0: E2.01 setting
1: Analog AI1 reference
3: Panel potentiometer setting
4: High-speed pulse setting
5: Communications reference
6: Multi-stage command reference
0
E2.01
PID keyboard reference
0.0% to 100.0%
50.0%
E2.02
PID feedback source
0.Analog AI1 reference
2. Panel potentiometer setting
4: High-speed pulse setting
5: Communications reference
0
E2.03
PID action direction
0: Positive
1: Negative
0
E2.04
PID setting feedback range
0 to 65535
1000
E2.05
PID inversion cut off frequency
0.00 to F0.19(Maximum frequency)
0.00Hz
E2.06
PID deviation limit
0.0% to 100.0%
2.0%
E2.07
PID differential limiting
0.00% to 100.00%
0.10%
E2.08
PID reference change time
0.00s to 650.00s
0.00s
E2.09
PID feedback filter time
0.00s to 60.00s
0.00s
E2.10
PID output filter time
0.00s to 60.00s
0.00s
E2.11
PID feedback loss detection value
0.0%: not judged feedback loss
0.1% to 100.0%
0.0%
E2.12
PID feedback loss detection time
0.0s to 20.0s
0.0s
E2.13
Proportional gain KP1
0.0 to 200.0
80.0
E2.14
Integration time Ti1
0.01s to 10.00s
0.50s
E2.15
Differential time Td1
0.00s to 10.000s
0.000s
E2.16
Proportional gain KP2
0.0 to 200.0
20.0
E2.17
Integration time Ti2
0.01s to 10.00s
2.00s
E2.18
Differential time Td2
0.00 to 10.000
0.000s
E2.19
PID parameter switching conditions
0:No switching;
1:Switching via terminals
2: Automatically switching according to
deviation.
0
E2.20
PID parameter switching deviation 1
0.0% to E2.21
20.0%
E2.21
PID parameter switching deviation 2
E2.20 to 100.0%
80.0%
E2.22
PID integral properties
Units digit: Integral separation
0: Invalid; 1: Valid
Tens digit: Whether stop integration when
output reaches limit
0: Continue; 1:Stop
00
E2.23
PID initial value
0.0% to 100.0%
0.0%
