11 - INTRODUCTION: ELECTRONIC SYSTEM’S TECHNICAL FEATURES
“Triex TOP” Control Board runs with a 32-bit processor able to perform 40 million instructions per second, with features which are
specic to electric motors control. Its processor can manage the entire operator setting, such as the motor, the encoder1 and even
receive a radiofrequency code from a transmitter.
It is endowed with an EEProm2 memory which stores the acquired remote controls’ codes in a encripted way. This memory can be
removed to be used in another compatible PPA product, such as PPA’s loose receiver ‘Alcance’ and vice versa. The control board is also
compatible to rolling code remote controls, with PPA’s protocol.
The system actuation can be performed via remote control through a embedded radiofrequency receiver, a loose receiver or any other
device with an NC (Normally closed) contact, such as a pushbutton.
The gate’s position control is performed through a PPA’s patented encoder system called “Reed Digital”.
12 - CONTROL BOARD
12.1 - Overview
