PPA DZ 1500 - Follower Photocell Function (FSG); Operator Strength Adjustment (FOP)

23
“FSG” (Switches #1 and #7)
ENABLING FOLLOWER (MIRRORED) PHOTOCELL.
In some facilities, such as gated communities, it is
necessary to the gate to close automatically as soon as the
vehicle gets out from the gate path. In order to do so, one
must install one photocell and enable the 'follower' (AKA
mirrored) function.
Press '+' to enable it and include the period of time
allowed before the automatic closing.
The minimum level is zero (0 – LED blinking) and it
increases one levl at a time (1) up to its maximum
60-second level (LED lit).
Example: LED blinking (function disabled). When pressing
the '+' button once, the LED is turned o and the 'follower'
function is enabled. The pause time before the automatic
closing begins is zero (0) second. If one presses the button
once more, the pause now is one (1) second. And so on, up
to sixty (60) seconds, when the LED lits.
“TM” (Switches #1 and #8) Reserved for future use.
“LUZ” (Switch #2)
Courtesy light timing.
Selects the time interval the 'LG' output is kept activated
afer the gate closing. It increases ten seconds at a time
(10s), from zero (0s) up to two-hundred forty seconds
(240s). This output is automatically activated when a
switch from the DIP switch is activated or the acquiring
process begins.
“VFC” (Switch #3)
Speed at the travel’s limits
Speed adjustment for starting and stopping region
•Dip3to"ON"("VFC");
•"(+)"Buttonincreasesthespeed;
•"(-)"Buttondecreasesthespeed;
In gates, the adjustment is from 5 of 5 Hz, from
15Hz up to 30Hz.
“VEL” (Switch #4)
Gate: Adjust the speed of opening and closing
Gate.
•Key4to"ON"("VEL");
•"(+)"Buttonincreasesthespeed;
•"(-)"Buttondecreasesthespeed;
The adjustment is from 10 to 10Hz, from 60Hz up to
150Hz.
“PAA” (Switch #5)
Gate:
TURN THE PAUSE OFF THROUGH A COMMAND DURING
OPENING.
When the operator is installed on gated communities,
it may be necessary to turn the function which 'stops'
(pauses) the gate o when receiving a command during
opening.
Press either the '-' button to turn the opening pause o
(LED blinking) or the '+' button to turn it on (LED lit).
“FOP” (Switch #6)
ADJUST OPERATOR "STRENGTH".
The operator, by default, has its strenght on maximum
level. One can decrease it in case it is necessary. Press '-'
button to decrease the strenght and '+' to increase it.
The minimum level is 40% (LED blinking) and increases
four levels at a time (4%) up to the maximum 100% level
(LED lit).
If the strenghth is in a very low level, the gate operator
won't work with maximum speed.
For more information see topic “14.1”
“VST” (Switch #7)
Gate's start speed.
To change it: press '-' button to decrease and '+' to
increase.
Minimum 20Hz (OSC LED blinking) increasing from 10Hz
up to 60Hz ('OSC' LED lit).
