PR electronics 4510V101- UK - Iecex Installation Drawing

IECEx Installation drawing 4500QI01-V2R0
Ex Certificates IECEx DEK 13.0026X
Standards: IEC 60079-0
IEC 60079-7
Marking: Ex ec IIC T5 Gc
Temperature range -20°C ≤ Ta ≤ +60°C
IECEx Installation Instructions
For safe installation of the 4500 series of products the following must be
observed.
Unclassified Area
Hazardous Area
PR
9000
PR
9000
PR
9000
4511
4511
4511
IP 54
T
Gateway
PLC/DCS
HMI/PC
Modbus RTU
Unclassified Area
Hazardous Area
PR
9000
PR
9000
PR
9000
4510/
4512
IP 54
4510/
4512
4510/
4512
IECEx Installation Drawing
4510V101-UK 13
